    Secondary Mining Rock Crusher , Limestone PFW Impact Crusher Heavy Rotor Design

    Ask Lasest Price
    Brand Name : YKcrusher
    Model Number : pfw1214
    Certification : iso9001
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 50
    Price : negotiable
    • Product Details
    • Company Profile

    Secondary Mining Rock Crusher , Limestone PFW Impact Crusher Heavy Rotor Design

    Secondary Mining Rock Crusher , Limestone PFW Impact Crusher Heavy Rotor Design


    Base on the plentiful experience of producing and marketing of impact crusher, SCM R&D institution designed the PFW series impact crusher. It is the newest style impact crusher and has been widely used in many industries, like chemical, metallurgy, road and bridge construction and sand making and so on.

    Features

    • Advanced Manufacture process and high-end fabrication material
    • Heavy rotor design and tight test method improve the rotor performance.
    • Overall type cast steel structure bearing base improves anti load resistance capacity.
    • Hydraulic jacking device and hydraulic regulated discharging port is helpful to save labor and time.

    Application

    PFW series Impact crusher are mostly used as secondary crusher and it well fits for crushing numerous medium and soft mineral &rock materials, such as limestone, feldspar, calcite, talc, barite, clay, tombar thite, kaolin, gypsum, and graphite, etc.

    Technical Data

    ModelRotor spec (mm)Feed opening (mm)Maximum feeding size (mm)Capacity(t/h)Power(kw)Overall dimension (mm)
    PFW1214IIФ1150×14001100×1430500130-2001322400×2310×2550
    PFW1315IIФ1300×15001200×1530600180-3202002700×2570×2800
    PFW1318IIФ1300×18001200×1830700240-4002502700×2870×2800
    PFW1415IIФ1400×15001450×1530700300-4802502900×2700×3000
    PFW1214ⅢФ1150×1400570×143025090-1701322550×2310×2100
    PFW1315ⅢФ1300×1500625×1530300180-2702002960×2570×2380
    PFW1318ⅢФ1300×1800625×1830300220-3002502960×2870×2380
    PFW1415ⅢФ1400×1500800×1530350280-3502503120×2650×2660

    pfw impact crusher
