Composite Mining Rock Crusher, Vertical Compound Crusher, Composite
Crusher Price, Iron Ore Beneficiation Plant
Product Description
Composite crusher, also known as vertical compound crusher, is a
kind of crushing machine which combining the advantages of impact
crushers and hammer crushers. It has the characteristics of high
reduction ratio, low power consumption, stable performance and easy
maintenance, etc.
Applications
Our compound crusher is mainly used to crush cement raw materials
and cement clinker. It can also be applied to crush iron ore,
sandstone, plaster, coal gangue, lump coal, limestone, dolomite,
granite, basalt and other stones. Composite crusher is a kind of no
screen, adjustable fine crushing machine. It is optimal designed on
the basis of advanced fine crushing technology both at home and
abroad. It is mainly adapted to medium-sized raw materials and
clinkers , at the same time can also be used for fine-crush
dolomite, coke precious stones, lead-zinc, serpentine, blast
furnace slag, coal gangue , phosphate rock materials with medium
hardness , especially suitable for hard limestone, dolomite,
granite, basalt artificially build sand or highway pavement stone
processing.
Technical Parameters
| Model | 800 | 1000 | 1250 | 1500 | 1750 |
| Roller Diameter (mm) | 650 | 800 | 1000 | 1250 | 1560 |
| Cylinder Height (mm) | 800 | 850 | 850 | 1000 | 1410 |
| Spindle Speed (r/min) | 1350 | 970 | 740 | 650 | 600 |
| Feed Size (mm) | 50 | 70 | 100 | 100 | 100 |
| Discharge Size (mm) | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 |
| Capacity (t/h) | 5-15 | 10-30 | 20-60 | 30-80 | 40-100 |
| Power (kw) | 30 | 55 | 75 | 110 | 132 |
| Rotation Rate (r/min) | 1440 | 1440 | 750 | 750 | 750 |
Dimensions (LxWxH) (mm) | 2200×860×1980 | 2700×1160×2000 | 2800×1400×2730 | 3100×1900×2300 | 3350×2100×2800 |
| Weight (t) | 2.3 | 4.5 | 9.73 | 18.1 | 26.61 |
