Portable Movable Gold Trommel Wash Plant With Wheel, High
Performance Gold Washing Plant, Rotary Trommel Screen
Product Description
The Mobile gold wash trammel screen is designed for alluvial/placer
gold ore processing, it's consist a half covered trommel screen,
one diesel engine/ electric motor, water pump& water pipes, and
other facilities such as the feeding hopper and the mobile system.
This mobile trommel machine normally working together with sluice
box , gold centrifugal concentrator and shaking table to form a
complete concentration plant.
Screen Diameter&length, sieve mesh size, the lay quantity of
screen can be customized.
Screen material can be rubber or steel.
The small mobile gold washing trommel screen completely according
to your needs.
Application
This mobile gold wash trammel screen is popular in Africa, Asia,
South America due to its easy to move and easy operation, low cost.
It has been widely used for alluvial gold, placer gold, tantalite,
niobite, and tin ore concentration.
The major use of this machine is washing clay, then classifying the
ore into two or three grade, and then feeding the material we need
into the mineral concentrator.
Main Features
1. High efficiency and high performance: this trommel machine get a
capacity up to 70 tons/hour, and it's could work continuously. With
the diesel engine power supply system and the water pump, there's
no need extra power and accessories.
2. Easy to move and install: with wheels and the adjustable
holders, this machine could be driven by a pick up or carried by a
small track. And when you need to start the work, the adjustable
holder will make it very easy to make the machine in balance, and
ready for work.
3. Easy and convenient operation: this machine is half automatic
all-in-one plant, only need the feeding of material. And the power
supply system, water supply system is mounted in the machine, which
is very convenient for operating.
4. Strong body: considering the road conditions in Africa, our
engineer has redesigned the frame, at the same time, we use thicker
and stronger material for all the part. As you can see the details
in the pictures bellow. Make sure this machine could working under
different conditions and no need too much service.
Technical Parameters
| Model | Screen Size (mm) | Rotation Rate (r/min) | Feeding Size (mm) | Water Consumption (m3/h) | Capacity (t/h) | Power (kw) | Weight (t) |
| GTX1030 | ≤20 | 27.9 | ≤80 | 1 | 40 | 15 | 3.8 |
| GTX1230 | ≤25 | 27.6 | ≤100 | 1.3 | 70 | 22 | 6.7 |
| GTX1430 | ≤25 | 27.6 | ≤100 | 1.5 | 80 | 22 | 10 |
| GTX1545 | ≤25 | 21 | ≤160 | 1.7 | 120 | 30 | 13 |
| GTX2265 | ≤50 | 19 | ≤230 | 1.8 | 180 | 37 | 16.9 |
